- Model: MAG 342CQR E2
MAG 342CQR E2
- VA Panel – Provides 1ms MPRT response time, optimizes screen
colors and brightness.
- 180Hz Refresh Rate – Respond faster with smoother frames.
- 1ms MPRT Response Time – Eliminate screen tearing and choppy
frame rates.
- AI Vision – The new AI Vision technology can not only reveal
details in dark areas but also enhance overall brightness and saturate colors.
- Less Blue Light – Use a software solution to reduce the
light emission in the blue-violet region of the blue light spectrum.
Specification | |
Panel
Size | 34"
(86.36 cm) |
Active
Display Area (mm) | 797.22(H)
x 333.72(V) |
Curvature | Curve
1500R |
Panel
Type | VA |
Panel
Resolution | 3440 x
1440 (UWQHD) |
Pixel
Pitch (H x V) | 0.23175(H)
x 0.23175(V) |
Aspect
Ratio | 21:9 |
Brightness
(nits) | 300
(Typ.) |
Contrast
Ratio | 3000:1
(Typ.) |
DCR | 100000000:1 |
Signal
Frequency | 68.47~268.2KHz(H)
/ 48~180Hz(V) |
Activated
Range | 48 to
180Hz |
Refresh
Rate | 180Hz |
Response
time | 1ms
(MPRT) |
Dynamic
Refresh Rate Technology | AMD
FreeSync™ Premium |
HDR
Support | HDR
Ready |
Video
ports | 1 x
DisplayPort 1.4a 2 x
HDMI™ 2.0b(UWQHD@100Hz) |
Audio
ports | 1 x
Headphone out |
Viewing
Angle | 178°(H)
/ 178°(V) |
Adobe
RGB / DCI-P3 / sRGB | 93% /
95% / 119% |
Surface
Treatment | Anti-glare |
Display
Colors | 1.07B ,
10 bits (8 bits + FRC) |
Frameless
Design | Yes |
PIP /
PBP Function | Yes |
Power
Type | External
Adaptor 19V 3.42A |
Power
Input | 100~240V,
50/60Hz |
Adjustment
(Tilt) | -5° ~
20° |
Adjustment
(Swivel) | -30° ~
30° |
Adjustment
(Pivot) | -5° ~
5° |
Adjustment
(Height) | 0 ~ 90
mm |
Kensington
Lock | Yes |
VESA
Mounting | 75 x 75
mm |
Weight
(NW / GW) | 6.95kg
/ 10.05kg 5.4kg(without
stand) |
Dimension
(W x D x H) | 808.60
x 269.97 x 513.97mm 808.60
x 119.67 x 363.95 mm (without stand) |
Carton
Dimension (W X D X H) | WW
carton: 948 x 210 x 487mm Outer:
963 x 225 x 509mm |
Warranty | 3 years |
Note* | Price, feature and
specifications are subject to change without notice. DisplayPort:
3440 x 1440 (Up to 180Hz HDMI™
2.0b: 3440 x 1440 (Up to 100Hz) Adobe
RGB, DCI-P3 and sRGB follow CIE1976 Standard |
